john deere motorgrader 670g

$139,000

The Caterpillar 140G Motor Grader is known for its reliability, durability, and performance in grading and road maintenance applications. With a powerful engine, efficient hydraulic system, and precise moldboard control, it is an excellent choice for construction, roadwork, and land development projects.


  • Manufacturer: John Deere

    Model: 670G

    Condition: Used

    • Model: John Deere PowerTech™ PSS 9.0L

    • Net Power: 235 hp (175 kW)

    • Displacement: 9.0 liters (549 cubic inches)

    • Number of Cylinders: 6

    • Net Torque Rise: 56%

    • Peak Engine Torque: 1,225 Nm (904 lb.-ft.)

    • Overall Length: 8,890 mm (29 ft. 2 in.)

    • Width Over Tires: 2,490 mm (98 in.)

    • Height to Top of Cab: 3,180 mm (10 ft. 5 in.)

    • Blade Base: 2,570 mm (8 ft. 5 in.)

    • Wheelbase: 6,160 mm (20 ft. 3 in.)

    • Turning Radius: 7.21 meters (23 ft. 8 in.)

    • Articulation Angle (Left/Right): 22 degrees

    • Operating Weight: 19,230 kg (42,395 lb.)

    • Blade Pull: 15,501 kg (34,173 lb.)

    • Fuel Capacity: 416 liters (110 gallons)

    • Hydraulic System Fluid Capacity: 60.6 liters (16 gallons)

    • Type: Direct-drive John Deere PowerShift Plus™, modulated shift-on-the-go

    • Number of Forward Gears: 8

    • Number of Reverse Gears: 8

    • Maximum Forward Speed: 45.5 km/h (28.3 mph)

    • Maximum Reverse Speed: 45.5 km/h (28.3 mph)

    • Pump Flow: 212 liters per minute (56.1 gallons per minute)

    • Relief Valve Pressure: 18,960 kPa (2,750 psi)

    • Width: 3,660 mm (12 ft.)

    • Height: 610 mm (24 in.)

    • Thickness: 22 mm (0.87 in.)

    • Side Shift (Left/Right): 683 mm (26.9 in.)

    • Maximum Depth of Cut: 490 mm (19.3 in.)

    • Shoulder Reach Outside Wheels (Left/Right): 2,083 mm (6 ft. 10 in.)

    • Circle Rotation: 360 degrees

    • Front Axle Ground Clearance: 610 mm (24 in.)

    • Front Wheel Lean (Left/Right): 20 degrees

    • Frame Articulation: 22 degrees

    • Tire Size: 14.00-24

    • Electrical System Voltage: 24 volts

    • Alternator Rating: 130 amps (standard); optional 200 amps
